240L Dustbin Mould

Product General Information:

Product name	240L dustbin mould
Weight	8.7Kg
Shrinkage	1.8%
Material	HDPE
Mould size	144014801680
Recycle time	130s
The type of injection machine	HT2400

Description:

The 240L dustbin mould is a premium, heavy-duty injection molding solution engineered specifically for the high-volume production of 240-liter plastic waste containers. Tailored to meet the rigorous standards of modern sanitation, logistics, and industrial waste management, this mould is an ideal choice for urban sanitation departments, large-scale manufacturing hubs, logistics terminals, shopping malls, and comprehensive residential complexes.

Fabricated from premium-grade mold steels such as 718H, S136, or H11, the mould core and cavity undergo sophisticated nitriding and quenching heat treatment processes, resulting in exceptional hardness, superior wear resistance, and remarkable corrosion resistance. These properties enable the mould to withstand the high injection pressures required for large-capacity 240L dustbin production, ensuring long-term stable operation without deformation or damage.

The mould base is constructed from high-tensile C45 pre-hardened steel, providing robust structural support and eliminating the risk of deformation during prolonged high-pressure injection cycles. For harsh working environments—such as humid areas, coastal regions, or corrosive industrial zones—custom options include nickel-plated alloy steel or high-quality bronze components, significantly extending the mould’s service life and reducing maintenance costs.

Structurally, the mould adopts a scientific single-cavity design, optionally equipped with a precision 4-point hot runner system. This ensures uniform plastic flow, minimizes material waste, and optimizes production efficiency. Strictly adhering to international HASCO standards, it is fitted with high-precision HASCO hydraulic cylinders and reliable Taiwanese hydraulic sliders, guaranteeing smooth operation and effortless demolding.

The integrated cooling system is optimally designed to shorten the molding cycle to 35-120 seconds, perfectly matching the mass production needs of 240L dustbins. With a stringent tooling tolerance of ±0.05mm, the mould ensures consistent product dimensions, smooth surfaces free of burrs or shrinkage marks, and a perfect fit for subsequent assembly processes. It supports custom texturing, high-gloss finishes, and custom logo printing, while being compatible with a wide range of materials including HDPE, PP, and ABS.

All key components comply with international HASCO standards, facilitating easy maintenance and quick replacement of wearing parts. This 240L dustbin mould not only meets the high-volume production demands of urban sanitation, industrial zones, and logistics parks but also delivers cost-effectiveness and long-term reliability, making it an indispensable production asset for manufacturers focusing on quality and efficiency.

Crafted from high-quality mold steel (HP20, H718, 2738, S136), the 180L dustbin mould undergoes professional nitriding, quenching and heat treatment processes. These strict processing steps significantly enhance the mould’s hardness and wear resistance, enabling it to withstand the higher injection pressure required for 180L large-capacity dustbin production. The mould’s core structure is designed to bear the high pressure of injection molding, avoiding deformation or damage even under long-term continuous operation, which fully meets the production requirements of large-capacity dustbins.

Its high-strength C45 steel mold base provides robust structural support, ensuring that the mould remains stable and reliable during long-term high-pressure injection cycles. For humid, coastal or corrosive environments, we offer customized material options—nickel-plated steel or bronze can be selected to enhance corrosion resistance, effectively extending the mould’s service life and reducing maintenance costs for manufacturers.

Structurally, the mould adopts a scientific single-cavity design, optionally equipped with a 4-point hot runner system. This system ensures uniform plastic flow, minimizes material waste, and further improves production efficiency. Strictly complying with international HASCO standards, the mould is equipped with HASCO high-quality hydraulic cylinders and Taiwan Junfan hydraulic sliders, ensuring smooth operation and easy demolding. This not only avoids burrs and other defects but also reduces post-processing workload.

The integrated cooling system is reasonably designed to shorten the molding cycle to 30-100 seconds, perfectly matching the mass production needs of 180L dustbins. With a tooling tolerance of ±0.1mm, the mould ensures consistent product dimensions, making the produced dustbins fit perfectly with subsequent assembly processes. It supports texture and high-gloss processing, as well as customized logo printing, fully meeting the quality requirements of global manufacturers.

All key components of the mould comply with international HASCO standards, facilitating easy maintenance and replacement of wearing parts. Whether for municipal waste treatment, industrial waste disposal or large-scale residential area use, this 180L dustbin mould can adapt to different working environments, providing reliable, cost-effective and efficient production solutions for global manufacturers. It is not only suitable for large-scale municipal waste stations and industrial zones but also perfectly compatible with existing production lines, helping manufacturers reduce operational costs and improve market competitiveness.
